During a boiler service there are a number of parts that are checked in order to keep the boiler operating safely.
This 1st image is of a set of electrodes that are in a Worcester CDi Classic boiler. These electrodes are constantly in the flame when the main burner is on. The electrode on the left helps detect flame. If this electrode is to short and is not in contact with the flame the boiler will think there is a fault and cut off the gas supply to the boiler. The 2 electrodes on the right create the spark to ignite the flame. It’s important that the distance between them are as stated in the manufacturers instructions in order to operate correctly.
This next image is of a seal for a Glowworm boiler. The seal was attached to the flue which is responsible for getting rid of the emissions of the boiler. This caused products of combustion mixing with the air being sucked into the boiler from outside. In turn this meant the boiler was noisy and not performing properly at the cost of the customer.
If the seals in the picture above and below where left in the boiler they would become hard, brittle, and stop protecting the boiler by keeping the heat in the correct place. This gasket can be found in many Worcester boilers.
These parts do not always require changing every year. A lot depends on the level of use of the appliance and the quality of the parts. As can be expected the parts that are in the more expensive boilers tend to last longer.
To arrange a boiler service with Pavlou Plumbers please either call on 01244 888801 or email email@example.com
This time of year, when the weather starts getting colder is when I get more new customers asking for boiler services. A few of these new customers canceled their British Gas or Homeserve or other larger company service contracts mainly because they feel they are not getting value for money. Not because the cost of the contracts are high but because the service provided is not sufficient.
The one sentence or phrase I hear time and time again after, or during a boiler service is something along the lines of “No one has ever spent this much time servicing our boiler” or “No one has ever stripped the boiler down like that before”. I was servicing a gas fire the other day and the customer mentioned the fire hadn’t been stripped down in 20yrs even though it had been “serviced” regularly. That did explain why that customer had black marks above the fire which would indicate products of combustion were entering the room, which is immediately dangerous. The last time I checked British Gas charge a similar amount than Pavlou Plumbers for their boiler service. The reason why they rarely actually service the boiler is because British Gas and other larger companies have much higher running costs
Not servicing a gas fire properly is lazy and dangerous however not actually servicing a modern boiler may not be. This is because manufacturers have designed their boilers in such a way that they will still work if they are not serviced, and they specify in the manufacturers instructions that if the emissions, and the gas pressure / fan pressure fall with in certain parameters then a service is not actually required. However I say why let it get that bad. Also if you do not strip the boiler down you can not check the condition of certain seals or electrodes. If your boiler is less than 3 or 4 years old then it’s unlikley that any seals or electrodes require replacing however every house is different. Some boilers get used more than others so the only way to be certain is to actually check the parts by stripping the boiler.
As long as the manufacturers instructions for the gas appliance is available then Pavlou Plumbers can service the appliance, properly.
Have a look at our YouTube channel to see some time lapse videos of boiler services performed by Pavlou Plumbers.
Here are some videos of what to expect when you get a boiler service from Pavlou Plumbers.
With only 4 moving parts Intergas boilers are innovative and built to last. They are the most efficient boilers and non of their heat exchanges have ever had a mechanical failure. Intergas is a Dutch company with over 50yrs in the industry that have saturated the market in the Netherlands. Mainly because any of their boilers can be fitted to any type of heating system. Whether it’s a combi system, a system with an unvented hot water cylinder or an old gravity system any Intergas boiler can fit into it, and what’s even better is the boiler can change into a combi boiler or a system boiler or even just a water heater if need be. The intergas boiler really is revolutionary.
Have a look at this YouTube video.
I can’t remember how many times I’ve been asked why a radiator or two are not working or why a radiator takes longer to heat up than others or why a room is colder than the others, or why a radiator doesn’t get as hot as others. For these scenarios we would make sure the radiator valves are working properly, then we would need to determine if there could be a blockage in the pipes and one question we would ask, if it isn’t obvious is “has this radiator been added onto the system after the original heating system was fitted?” This scenario would arise from having an extension with new rooms with radiators in them, or some renovations where radiators have been changed.
If the answer is “yes” and it was proven that the issue is not the radiator valves or a blockage in the pipework, we would then need to find out how the radiator has been plumbed into the heating system. When we do find out the result 99% of the time is the 1st fix plumbing was not done properly. By this I mean either the pipe size is too small, or where the pipes branch off to the new radiator is plumbed in the wrong place, or there are too many bends in the pipe. Either way the end result is the customer will have to pay for the plumbing to be done again, and pay for the plastering to be done again and the painting to be done again because the person who did the work won’t come back, because they’ve already been paid in the summer when the work was done but you’ve only realised now because it’s winter, or something like that. Obviously I’m generalising on the scenario as I know there are good plumbers who do pay for their mistakes, and there are some plumbers who don’t.
There are laws in place which mean you could take legal action against the company involved but it’s not straightforward and you’ll need to get a solicitor involved etc, etc. Basically it’s a massive hassle.
If you are planning an extension or renovation make sure of the following:-
If you make sure the above questions have been dealt with you have done all you can to have a properly working heating system, or at the very least won’t cost you an arm and a leg to rectify.
Below is a before and after picture of a radiator installation. The radiator in the room was undersized which meant the room was never warm in the colder months. For this job we had to fit larger pipes going to the radiator, then fit a larger radiator after the walls were plastered.
Pavlou Plumbers have years of experience in plumbing in heating systems properly so if you’re planning a renovation, extension or need a new heating system get in touch with Pavlou Plumbers.
Even though recent temperatures have been around 27 degrees celsius it’s always recommended to switch your heating on for 5 – 10 minutes every couple of weeks to avoid any mechanical parts seizing. Depending on the type of heating system you have and its condition parts such as the pump and motorised valves can get stuck in one position if left un-used for too long. These parts can seize on all systems however older, open vented systems are more prone than others. Open vented heating systems are those that have water tanks in the loft. As the water in the system is open to the atmosphere oxygen can get back into the water which causes rust. As you may know the black sludge in the heating system is unoxidised rust. This sludge is magnetic and would stick to the magnet in the pump motor. The sludge can also block up other parts such as the heat exchanger on the boiler and the pipes themselves, in a similar way that eating a high fatty diet would block up your arteries.
If you know you have an old heating system that has not been treated or flushed in the last 5 years, then ultimately the best thing to do is to have a central heating flush. However in the meantime turning on the heating system for a few minutes will prolong the life of the parts on the heating system. If sludge is left to settle the sludge turns into a solid. For those of you who have smart heating controls have the benefit of being able to turn the heating on remotely while they are not home, so they’ll stay comfortable
If you have any concerns regarding your heating system get in touch to arrange a free review.
As from April 2018 there will be new rules that must be followed when installing a combi boiler in order to comply with new government legislation in the UK. The reason being the current regulations came about a long time ago and there is new technology out now that makes heating your home and hot water even cheaper. The main aspects of the new legislations means that one of the following needs to be installed when fitting a new combi boiler.
I’ll briefly explain what these four different options are.
Flue gas heat recovery systems – This is another heat exchanger that would sit on top of your boiler, and would extract the very little heat from the fumes that go through the flue of the boiler. This heat exchanger would then apply that heat to the cold water inlet of the boiler.
This flue gas heat recovery system takes up a lot more space and costs around £500 / £800 plus fitting. Not exactly my first choice.
Weather compensation – A weather compensator would be an additional feature of your heating controls (timer). This would measure the outside temperature, using a sensor or online information and switch your heating on later on a warmer day and earlier on cooler days. These can vary in price depending on the boiler you have.
Load Compensator – This means the boiler would increase the water temperature in your radiators when the house is cold and not so much when the house gets warmer. As far as I’m aware these are only available when you use certain boiler manufacturers own more expensive heating controls on their own boilers. Alternatively if you have a boiler and heating control that supports OpenTherm then this would compensate the load, however this is very rare at the moment. Again, as far as I’m aware only certain Ideal and InterGas boilers currently have OpenTherm.
Smart controls featuring automation and optimisation functions – There are a lot of ‘smart’ heating controls available at the moment however, the only ‘smart’ control that would not only provide automation and optimisation functions but would also act as a weather compensator when connected to the internet, and a load compensator if installed with an OpenTherm compatible boiler would be the Nest Learning Thermostat. The Hive, Tado, Salus and all the others do not work like the Nest.
Even though the Nest Learning Thermostat can be used with an internet enabled device the Nest will save you money because it automates your heating. What does that mean? As the Nest has a motion sensor built into the device if the Nest does not see any movement for a while then it won’t switch the heating on. What it also means is you would never have to programme the heating schedule again. All you would do the 1st few days you have the Nest is to turn the temperature to your preferred temperature when you are home and when you are away or in bed and that’s it.
The Nest Learning Thermostat can do a load more stuff, too many to mention in this blog so I’ll just say The Nest or the Nest E (cheaper version) really is the best there is for most boilers. The Nest can be fitted to any heating system, not just combi boilers. The Nest will make even the oldest boiler a lot more efficient. Your standard heating controls would be charged from around £50 upwards. To have a weather compensator fitted could cost an additional £60 plus depending on the boiler. The Nest currently cost £200 and the Nest E will be cheaper when it is available in the UK. Fitting a Nest control to a combi boiler would be my first recommendation because they are easy to fit and comply with the new regulations.
For more information on how to get a new boiler or better heating controls feel free to contact Pavlou Plumbers.
Here’s a picture of Louie because he’s ace!
If there is one device in your home that will save you the most money on your heating bills it’s your room thermostat. This is the control that will switch off your heating when the room the thermostat is in reaches temperature. The thermostat should be positioned in the room that is used the most such as a living room. Previously the regulations stated the room thermostat control should be in the coldest room which was usually the entrance hall but now that has changed.
You may not realise but you do have a choice what heating controls you have. If you have no idea how to use your heating controls, or if you travel a lot, or if you are a landlord of a House of Multiple Occupancy who pays for the heating, or if you would prefer to have a heating control that has some style and is one of the most efficient heating control on the market the Nest heating control is for you.
Designed by former Apple employees amongst others this heating control is simple to use and will save you money. As well as being able to control your heating and hot water using any internet enabled device the nest thermostat is a learning thermostat. It learns how long your property will take to reach temperature and how long it takes for your property to cool down.
Although the Nest heating control does not need the internet to work when it is connected the Nest heating control will get local weather information to make sure your house reaches the temperature you want when you want it.
For those of you who travel a lot or for those of you who randomly have an empty house the Nest control will automatically know the house is empty and will deactivate your heating for you. For those of you who are landlords of HMO properties or if you would prefer certain members of your family or household not to play with the heating controls then the Nest heating controls can be locked so the temperature can not go higher or lower than your chosen numbers.
If you would like any heating control fitted then get in touch.
With all the changes currently going on the world right now non are as important to me as this. The main change I have to do in my working life is the amount of working hours. As many of you will know the 1st few months of a child’s life is the most precious and this time will never come round again. This is why I’m doing my best to spend as much time as possible supporting my wife by being with our son. I am also aware that not sleeping properly can affect one’s performance. This is another reason I think it’s a good idea not to work as many hours as have done.
Even though my wife and I have just had our 1st child I know the world does keep turning and my customers may need serving. This is why I have arranged for a friend who I trust with my customers to help me during this period. This is why Dan may be completing certain jobs for me. I would like to thank my customers who have accommodated my circumstances so far.
Please feel free to still get in touch with any plumbing and heating enquiries you may have as I will do my best to either see to your job myself or arrange for the work to be done by Dan.
Thank you from me and Louie Patrick Pavlou.
